Jib Crane Types
Jib cranes are made up of a trolley hoist on a horizontal load-bearing boom. This boom is attached to a pivoting vertical member and up to 20 feet long. Jib cranes could move loads between any areas within the boom's arc of rotation. Light duty models are utilized inside warehouses and factories for loads weighing up to 5 tons. The website BestJibCranes.com showcases the major kinds of jib cranes as being either wall-mounted, mast mounted or free-standing.
Free Standing
Free-standing jib cranes are able to stand alone not requiring support from the building structure. The horizontal boom in this case is connected to a pivoting vertical column that is anchored firmly to the floor of the building. This kind of jib crane could rotate a full 360 degrees and needs a foundation made of either steel or concrete.
Mast-Type
The vertical column on the mast-type jib cranes are supported by pivot points at the top and the bottom. These pivots are attached to the floor of the building and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the advantage of not requiring the massive foundation needed for free-standing units.
Wall Mounted
The wall-mounted jib cranes offer a horizontal boom that is attached to the wall of a building rather than the regular vertical column. These equipments offer up to 200 degrees of rotation and are great in places where the full 360 degree rotation is not needed.
There are two model varieties, depending on how the boom is supported. One of the types utilizes a tie rod which is attached from above the wall to the boom. The other type supports the boom from below by utilizing a cantilever brace that is connected to the wall also.
